Modelo: HM14/HM13F/CM6D30F/CM6D28F/CM6D18F
| Model | Unit | HM14.610 61 | HM13F.612 30 | HM13F.500 31 | CM6D30F.408 30 | CM6D28F.350 30 | CM6D18F.290 30 |
| Rated power/Speed | kW/rpm | 448/1700 | 450/1500 | 368/1500 | 408/1500 | 350/1500/ | 290/1500 |
| Overload power/Speed | kW/rpm | - | 505/1500 | 405/1500 | 450/1500 | 370/1500 | 320/1500 |
| Number of cylinders | - | 6 | 6 | 6 | 6 | 6 | 6 |
| BorexStroke | mm | 113x164 | 130x161 | 130x161 | 130x161 | 128x153 | 118x150 |
| Compression ratio | - | 20:1 | 17:1 | 17:1 | 17:1 | 17:1 | 17:1 |
| Displacement | L | 13.68 | 12.8 | 12.8 | 12.8 | 11.8 | 9.8 |
| Specific fuel consumption | g/kW·h | ≤186 | ≤184 | ≤189 | ≤184 | ≤186 | ≤186 |
| Oil capacity | L | 41 | 41 | 41 | 41 | 38 | 34 |
| Emission level | - | GB18352.6-2018Vlb | GB20891 China Phase III | ||||
| L×W×H | mm | 1641x1038x1220 | 1432x927x1204 | 1432x927x1204 | 1432x927x1204 | 1373x812x1138 | 1334x825x1137 |
| Weight | kg | 1084 | 1078 | 1078 | 1078 |
1065
|
980 |
| Recommended Rated power | kW | - | 400 | 320 | 360 | 320 | 260 |
| Recommended Overload power | kW | - | 450 | 370 | 400 | 350 |
290
|
